Loyd Auerbach, Director of the Office of Paranormal Investigations
rates it, "...by far the best ever available under $2,000."
As featured on the DISCOVERY CHANNEL program "On the Inside: THE REAL GHOSTHUNTERS", among the Ghost Hunting Equipment employed by professional Ghost Hunters during on-site Ghost Hunting research
Email: EMF Meters
 |
$169.99 plus Shipping & Handling
|
Detects changes in EXTREMELY weak static (DC or "natural") electric
and magnetic fields.
Unique SUM feature - allows simultaneous monitoring of electric and
magnetic fields (widely utilized by parapsychologists and ghost
hunters).
Designed by a Phd Physicist to ignore powerlines, appliances and other
man-made EMF sources, eliminating nearly all false positives and
negatives produced by nearly all EMF meters / detectors when utilized
for paranormal investigations, ghost hunting or parapsychological field
work.
Built-in Tone Alarm allows detection in darkened conditions as well
as at a distance from stationary positioning.
Since house construction materials generally do not block
magnetic fields, the meter can be used indoors to detect sources outside
the building or on the other side of an interior wall, etc.
Magnetic range: 0 to 100 Microteslas or 0 to 1,000 mG (milliGauss) - 1
Microtesla = 10 milliGauss - Resolution = 2.5 mG
Electric range: 0 to 1,000 V / m - Resolution = 3 V / m
Radio / Microwave range: 100 KHz to 2.5 GHz - Allows detection of strong
or unusual atmospheric electrical activity, microwave ovens (including
leakage), surveillance "bugs" (within a foot or two), cell phones and
cellular telephone towers (up to 300 feet distant).
One-Year Limited Warranty & will continue to perform indefinitely with
reasonable care!
AC Adapter & Input Port / Jack - Special connector piece included -
Add $25.00 (US, Canada and Mexico Only)
External Sensitivity Magnification Coil - Multiplies Magnetic Field
sensitivity by a factor of 10x (only on the Magnetic setting) - Includes
Output Jack for link up - Add $75.00
Output Jack / Analog Plug Option - Enables analog readout capability -
Allows interfacing the meter to voltmeters, computers, or any device
capable of interpreting an analog output. Maximum voltage is
approximately 300 mV and the output impedance is 10 KOHM - An Analog
Digital Card (available at computer stores) is a necessary item for
meter / computer linkage via the output jack - Available for an
additional 9.50
"Night light", a factory installed pair of red LEDs, special option
available for an additional 55.00. Illuminates the meter face, allowing
night readings without using a flashlight.
ON / OFF Switch for LEDs - LED "backlighting" can be switched on or
off while meter is set to the ON position - Available for an additional
9.50.
Another version of the Trifield Natural EMF Meter was produced, the
Model 2 , and equipped with a probe which is primarily useful for
detecting extremely high altitude UFO's., and is available at a higher
cost. READ MORE HERE
Shipped directly from the manufacturing facility, AlphaLab, Inc. See
order page for details.
 |
 |
Moon Phases |
Another Unique Ghost Hunting Instrument |
Multiple field "Natural" EM / MICROWAVE meter measures LOW static electric, radio-microwave and magnetic fields (skyborne magnetic sources, surveillance "bugs", electrical fields carried by humans &
animals).
The TriField Natural EM Meter detects changes in extremely weak static (or natural") electric and magnetic fields. It signals with both a tone and the movement of a needle-type gauge if either the electric or magnetic field changes from previous levels.
A radio and microwave detector is also included, which reads radio power directly if any transmitters are nearby. Since man-made AC electric and magnetic fields are very common and could interfere with readings of static fields, the meter has
been designed to ignore the AC fields of power lines, appliances, etc.
This meter was designed to satisfy the need for natural field measurements in specialized research areas. It can detect
"geomagnetic storms" caused by unusual solar activity interacting with the ionosphere (which results in rapid changes of up to
10% in the Earth's magnetic field), as well as the electrical activity of ordinary thunder storms. Ball lightning should in theory be
associated with a strong magnetic field, and magnetization of metal has been reported with some UFO sightings. When set on
MAGNETIC, the Natural EM Meter will signal the movement of any strong magnetic source in the sky, even if the sky is
cloudy or the source dips behind a hill. Since construction materials generally do not block magnetic fields, the meter can be placed indoors and work equally well. The built-in tone allows its use in the dark.
The meter is sensitive to changes of as little as 0.5% of the strength of the Earth's magnetic field, and the tone will sound
whether the field increases or decreases. If the magnetic field then becomes stable for more than about five seconds, the tone
will stop and the needle will return to zero. The
meter will remain at rest until the field changes again. The threshold level, or
"squelch", of the tone is adjustable. The user determines the amount of change in the magnetic field (within a 0.5 second
interval) required to sound the tone. If the field changes by a threshold amount, the
tone will come on at at lower pitch. If the amount of change is large, the tone will be higher.
When the dial is set to ELECTRIC, the meter is sensitive to electric
fields as weak as 3 V/m (volts per meter). To illustrate just how
feeble a field this is, a l0'xl0'xl0' room filled with a field of this
strength has a total amount of energy equivalent to that required to
lift a single grain of table salt 1/50th of an inch. Indoors, electric
fields typically fluctuate 1 or 2 V/m. By setting the minimum
sensitivity to change at 3 V/m, we have designed the meter to disregard
this "background noise".
Human beings and animals usually emit an
electric field which is easily detectable using the Natural EM Meter.
In fact, the meter can be used as a motion-activated intruder alarm. It
is so sensitive that it can detect the presence of a person through a
wall. Though it is not foolproof in this capacity, (sometimes a person
will carry NO electric charge and thus be "invisible" to the meter),
its sensitivity is of interest to researchers in the field of
parapsychology, especially "ghost hunters". Every type of detectable physical manifestation
requires a certain amount of energy. For example, "moving air" requires the expenditure of a small amount of energy to get the air to move initially.
Below is a table showing several types of effects or fields emitted by people and objects. It also shows the minimum amount of energy required (per cubic foot of air) to set up that effect or field so that it is stronger than typical indoor "background noise" for that effect or field. Clearly the static electric field is the type that requires the least energy to be detectable.
Type of Effect
or Field Energy Needed
(watts-seconds) Are instruments needed
to detect this? Type of Energy Effect or Field
Emitted by people?
Heat 30 Yes Thermal Viewer
Moving Air 1/10,000 Yes No (can feel this)
Static Magnetic 1/20 million No Magnetic Meter
Sound 1/100 million Yes No
Light 1/1billion No No
Static Electric 1/10 billion Yes Electric Meter
The radio/microwave detector is sensitive from 100,000 to 2.5 billion oscillations per second (100 KHz to 2.5 GHz) and can detect strong or unusual atmospheric electrical activity. It can also detect leaky microwave ovens, cellular or portable phones, walkie-talkies and concealed surveillance bugs. Its minimum and maximum detectable signal strengths are 0.01 milliwatt/cm2 and 1 milliwatt/cm2 respectively.
*Minimum resolution is 1/200 of full scale.
Natural EM Meter
Frequency Response Table
Frequency (Hz)
Magnetic Full Scale Equals (RMS milligauss)
Multiply Reading By
Electric Full Scale Equals (RMS Volts/Meter)
Multiply Reading By .5 330 3.3 2,000 20 1 580 5.8 2,000 20 2 1,000 10 2,300 23 5 1,500 15 2,500 25 10 2,500 25 2,800 28 20 3,000 30 5,000 50 50 3,300 33 16,000 160 100 3,500 35 50,000 500 200 3,500 35 500 3,300 33 1,000 3,000 30 2,000 2,300 23 5,000 2,000 20 10,000 2,500
